Productivity
Surface Mount Technology (SMT) Lines: 8 lines delivering a total daily output of 10.5 million placement points.
Through-Hole Technology (THT) Lines: 3 lines capable of assembling approximately 3,200 substrates per day.
Package Lines: 3 lines with a daily production capacity of approximately 600 units.
SMT LINES
8
10.5 Million chips / Day
DIP LINES
3
3200 PCS / Day
Ass'y LINES
3
600 PCS / Day
SMT Line
Machine Complement:
6x Panasonic Series Mounters
2x Yamaha Series Mounters
Placement Accuracy:
Panasonic: Down to 03015 metric size (0.3mm x 0.15mm)
Yamaha: Down to 01005 metric size (0.1mm x 0.05mm)
Inspection: All lines are equipped with SPI (Solder Paste Inspection) and utilize In-Line Automated Optical Inspection (AOI) for comprehensive quality control.
Process Environment: Nitrogen atmosphere is maintained throughout production to minimize oxidation and ensure component integrity.
Assembly Capabilities: Certain lines are equipped to handle complex Package-on-Package (POP) configurations.
8
Lines
for SMT
10.5
Million chips
Capacity/Day
DIP Line
Through-Hole Technology (THT) Line with Wave Soldering Capabilities
Soldering Equipment: Three CP3000 wave soldering furnaces provide efficient soldering for through-hole components.
Maximum Board Size: The DIP line can handle large boards up to 500mm in size.
Component Placement Flexibility: Four distinct cutting machines cater to diverse design requirements for component lead preparation.
Optional Equipment: Customers can choose to integrate a UV dispensing machine and a German-made In-Circuit Tester (ICT) based on their specific needs.
3
Lines
for DIP
3200
PCS(300*300mm)
Capacity/Day
Assembly Line
The assembly line is 60 meters long and 1 piece. The test packaging line is 36 meters long and 2 pieces. There is also a Module test line. The assembly line equipment includes hot press, ultrasonic press machine, vibration tester, Clean, Bench barcode printer Off Line. Both & On Line are available for purchase.
B/I Room There are currently 2 rooms for temperature monitoring from room temperature to 65 ° C. The sockets have independent timing functions.
3
Lines
for Ass'y
600
PCS(1U server)
Capacity/Day
